Preliminary steps
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page
48.
▶
"Getting access to the component" on page 50.
▶
Remove the system fan module, see "Removing the system fan module" on
page 82.
Removing the Dual microSD 64GB Enterprise
▶
Disconnect the cable from the connector "ROC" on the system board (see
Figure 292).
Figure 293: Removing the Dual microSD 64GB Enterprise
▶
Pull the Dual microSD 64GB Enterprise out of its connector.
Concluding steps
▶
Install the system fan module, see "Installing the system fan module" on
page 85
.
▶
"Reassembling" on page 66.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
System board and components
444 Upgrade and Maintenance Manual TX1330 M4
