Figure 303: Detaching the accessible drive cage (A)
▶
Remove two screws from the bottom side of the server as shown.
▶
Bring the server back to its horizontal position.
At least two people are needed to turn over a fully equipped server.
Remove HDDs and hot-plug PSUs in order to facilitate the task.
Converting a floorstand model to a rack model
TX1330 M4 Upgrade and Maintenance Manual 463
