Leave the server in its upside down position.
Removing rubber feet
Figure 302: Removing rubber feet
▶
Using a slotted screw driver
, slightly pry up on each rubber foot until it
detaches.
▶
Bring the server back to its horizontal position.
At least two people are needed to turn over a fully equipped server.
Remove HDDs and hot-plug PSUs in order to facilitate the task.
Removing the accessible drive cage
▶
Remove the front panel module, see "Removing the defective front panel
module" on page
405
.
▶
If applicable, remove all accessible drives, see "Removing an accessible
drive" on page 370
▶
If applicable, remove an HDD extension box, see "HDD extension box" on
page 241.
Converting a floorstand model to a rack model
462 Upgrade and Maintenance Manual TX1330 M4
