Figure 317: Removing the intrusion switch holder (B)
▶
Slide back the intrusion switch holder until it disengages from the HDD bay
top cover.
▶
Remove the defective intrusion switch holder.
Installing the intrusion switch cable
The rubber bumper is only necessary in case of rack server
configuration.
Cabling
480 Upgrade and Maintenance Manual TX1330 M4
