Figure 318: Attaching a rubber bumper to the front intrusion switch
▶
In case of rack server configurations, a rubber bumper needs to be
attached to the front intrusion switch as described below. When working
on a floorstand model, please skip this step.
Attach a rubber bumper (C26192-Y26-C43) to the front intrusion switch as
shown.
Cabling
TX1330 M4 Upgrade and Maintenance Manual 481
