245
Program description - Telemetry
This switchover is accomplished by moving the with
the selection key of the left or right four-way button
until the “ ” symbol is at the left margin of the bottom
line then tapping on the centre SET key of the right
four-way button:
RX CURVE V3.78
TYPE : A
CURVE1 CH : 02
TYPE : A
CURVE2 CH : 03
TYPE : B
CURVE3 CH : 04
5CH FUNCTION:SERVO
Now use one of the selection keys on the right
four-way button to select the alternative setting “SEN-
SOR”.
RX CURVE V3.78
TYPE : A
CURVE1 CH : 02
TYPE : A
CURVE2 CH : 03
TYPE : B
CURVE3 CH : 04
5CH FUNCTION:SENSOR
Another tap on the centre SET key of the right four-
way button will close the selection and, with appropri-
ate repetitive taps on the centre ESC key of the left
four-way button, a return to the transmitter’s basic
display is accomplished.
RX SERVO TEST
The RX SERVO TEST function allows you to test the
servos connected to the currently active receiver:
RX SERVO TEST V3.78
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUT TYPE:ONCE
Value Explanation Possible
settings
Vx.xx Receiver’s firmware
version
None
ALL-MAX Servo travel on the
"+" side for all servo
outputs for the
servo test
1500 … 2000 µs
ALL-MIN Servo travel on the
"-" side for all servo
outputs for the
servo test
1500 … 1000 µs
TEST Test procedure START / STOP
ALARM
VOLT
Alarm threshold
of the receiver
undervoltage
warning
3.0 … 7.5 V
factory setting:
3.8 V
ALARM
TEMP+
Alarm threshold for
excessively high
temperature of the
receiver
50 … 80 °C
Factory setting:
55 °C
ALARM
TEMP–
Alarm threshold
for excessively low
temperature of the
receiver
-20 … +10 °C
Factory setting:
-10 °C
CH
OUTPUT
TYPE
Channel sequence ONCE, SAME,
SUMI, SUMO and
SUMD
ALL-MAX (servo travel on the “+” side)
In this line you set the maximum servo travel on the
plus side of the control travel for the servo test.
2000 μs corresponds to the full throw; 1500 μs corre-
sponds to the neutral position.
Make sure that the servos do not overrun mechanically
during the test routine.
ALL-MIN (servo travel on the “-” side)
You adjust the maximum servo travel on the minus side
of the control path for the servo test in this line.
1000 μs corresponds to the full throw; 1500 μs corre-
sponds to the neutral position.
TEST
You start and stop the servo test integrated in the
receivers in this line.
A brief tap on the centre SET key of the right four-way
button will open the entry field:
RX SERVO TEST V3.78
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUT TYPE:ONCE
TEST : STOP
Now, with one of the selection keys of the right four-
way button, select START:
RX SERVO TEST V3.78
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUT TYPE:ONCE
TEST : START
A brief tap on the centre SET key of the right four-way
button will now start the test run. The input field is
shown as “normal” again:
