Program description - Telemetry
(described below) then its settings can be manually
select or activate in addition to the previously described
receiver screens:
However, to actually gain access to this data, the
selected sensor/s must be connected to the receiver
system and this receiver system must have an active
telemetry connection.
If, as described in the next section, there is at least
one sensor activated which has the support of current
firmware, then it is possible to directly switch between
individual modules. However, if sensors with older firm-
ware are in use, it may be necessary to select “etc.”
instead of the direct sensor selection.
In either case, tap the or selection key of the left
four-way button …
Between the displays automatically or possibly in the
submenu “SENSOR SELECT” of the “Telemetry”
menus manually activated sensors switch by or
either selection key of the left four-way key briefly ...
RECEIVER
etc.
GENERAL
… ... And select to display the selection window with
one of the two selection keys or the line of the
required sensor:
GENERAL
ESC AIR
RECEIVER
If the selected module, in this case a Vario module, is
active then on the last receiver screen (“RX SERVO
TEST”), at the top right there will also be an additional “
” symbol pointing to the right. This symbol is located
just to the right of the left-pointing “ ” symbol and is
the visible indicator that additional display screens can
be accessed:
RX SERVO TEST V3.78
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUT TYPE:ONCE
Now use one of the selection keys on the left or
right four-way button to switch to the selected sensor’s
displays and check or change its settings as described
in the manual delivered with the sensor.
GENERAL MODULE
RECEIVER
VARIO MODULE
ESC
GPS
ELECTR. AIR MODULE
To Next Page
