GW Instek GPT-9500 Series User Manual

GPT-9500 Series User Manual
138
Return to
Ready Status
1. The PASS/FAIL/STOP results will be held on
the screen until the STOP button is pressed.
Note
PASS HOLD will return to READY status
automatically after the set duration (page 97).
2. To put the tester back into READY
status, press the STOP button.
3. The READY indicator will be shown on the display.
AUTO
Page View
Display
for
READY
Status
Return to READY status
Normal
AUTO
Display
for
READY
Status
Return to READY status
PASS Timing
Diagram
Output V
time
START
TEST
PASS
step 1 ~ step 10
FAIL Timing
Diagram
Output V
time
START
TEST
FAIL
step 1 ~ step 10
