GW Instek GPT-9500 Series User Manual

APPENDIX
277
AC Withstanding Voltage
Output Voltage Range
0.050kV~ 5.000kV¹
Output Voltage Resolution
1V
Output Voltage Accuracy
(1% of setting +5V) with no load
Maximum Rated Load
150VA (5kV/30mA)
Maximum Rated Current
30mA
0.001mA~10mA(0.05kV~0.5kV)
0.001mA~30mA(0.5kV~ 5kV)
Output Voltage Waveform
Sine wave
Voltage Regulation
± (1% +5V)[Maximum rated load
Frequency
50 Hz / 60 Hz
Voltmeter Accuracy
± (1% of reading+ 5 V)
Current Measurement
Range
0.001mA~30.00mA
Current Best Resolution
1uA (0.001mA ~9.999mA)
10uA(10.00mA~30.00mA)
Current Measurement
Accuracy
± (1.5% of reading+30uA)
3
Current Offset
80uA Maximum
Judgment Accuracy
± (3% of setting+30uA)
3
ARC DETECT
YES
RAMP TIME (Rise Time)
0.1~999.9S
FALL Time
OFF~999.9S
WAIT Time
OFF~999.9S
TIMER (Test Time)
CONT²,0.3S~999.9S
TIMER Accuracy
+/-(100ppm+20ms)
GND
ON/OFF
1
2
3
At least 0.3 seconds is needed to reach a set voltage of 50V/10mA.
When setting greater than 100VA, the maximum test time is 600 seconds
followed by the identical rest time. Plus, overheat protection will be activated
and thus output will be stopped when test time is over 600 seconds.
When scan channel is activated, it is required to add 15uA for each channel.
