GW Instek GPT-9500 Series User Manual

GPT-9500 Series User Manual
278
DC Withstanding Voltage
Output Voltage Range
0.050kV~ 6.000kV¹
Output Voltage Resolution
1V
Output Voltage Accuracy
±(1% of setting +5V) With no load
Maximum Rated Load
50W(5kV/10mA)
Maximum Rated Current
10mA
Voltmeter Accuracy
± (1% of reading+ 5 V)
Voltage Regulation
± (1% +5V)[Maximum rated load ->no load]
Current Measurement
Range
0.001mA-10.00mA
Current Best Resolution
0.1uA (0.1uA~999.9uA)
1uA (0.001mA~9.999mA)
10uA(10.00mA)
Current Measurement
Accuracy
±(1 % of reading+ 1uA) , I< 1mA
±(1 % of reading+ 10uA), I>= 1mA
3
Current Offset
5uA Maximum
Judgment Valid Range
(DCW)
± (3% of setting+30uA)
3
ARC DETECT
YES
RAMP TIME (Rise Time)
0.1~999.9S
FALL Time
OFF~999.9S
WAIT Time
OFF~999.9S
TIMER (Test Time)
CONT²,0.3S~999.9S
TIMER Accuracy
+/-(100ppm+20ms)
GND mode
ON/OFF
Maximum Capacitive Load
DC Mode
1uF
1
2
3
At least 0.3 seconds is needed to reach a set voltage of 50V/2mA.
When setting greater than 40VA, the maximum test time is 600 seconds
followed by the identical rest time. Plus, overheat protection will be activated
and thus output will be stopped when test time is over 600 seconds.
When scan channel is activated, it is required to add 2uA for each channel.
