H3C S5120-EI Series User Manual

1-12
To do… Use the command… Remarks
Configure the number of
packets sent in a UDP jitter
probe
probe packet-number
packet-number
Optional
10 by default.
Configure the interval for
sending packets in a UDP jitter
probe
probe packet-interval
packet-interval
Optional
20 milliseconds by default.
Configure the time for waiting
for a response in a UDP jitter
test
probe packet-timeout
packet-timeout
Optional
3000 milliseconds by default.
Configure the source IP
address of a probe request in a
test operation
source ip ip-address
Optional
By default, no source IP
address is specified.
The source IP address must be
that of an interface on the
device and the interface must
be up. Otherwise, the test will
fail.
Configure common optional
parameters
See
Configuring Optional
Parameters Common to an
NQA Test Group
Optional
The number of probes made in a UDP jitter test depends on the probe count command, while the
number of probe packets sent in each probe depends on the configuration of the probe
packet-number command.
Configuring an SNMP Test
An SNMP query test is used to test the time the NQA client takes to send an SNMP query packet to the
SNMP agent and then receive a response packet.
Configuration prerequisites
The SNMP agent function must be enabled on the device serving as an SNMP agent before an SNMP
test. For the configuration of SNMP agent, see SNMP Configuration in the System Volume.
Configuring an SNMP test
Follow these steps to configure an SNMP test:
To do… Use the command… Remarks
Enter system view
system-view
—
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Configure the test type as
SNMP and enter test type view
type snmp
Required
