1-1
1 Ethernet Interface Configuration
General Ethernet Interface Configuration
GE and 10GE ports on the S5120-EI series Ethernet switches are numbered in the following format:
interface type A/B/C.
z A: Number of a member device in an IRF stack. If no IRF stack is formed, this value is 1.
z B: Slot number on the device. A value of 0 represents the slot where the fixed ports of the device
are located; a value of 1 represents the slot where the ports of interface expansion card 1 are
located; a value of 2 represents the slot where the ports of interface expansion card 2 are located.
z C: Number of a port on a slot.
For more information about interface expansion card, see H3C S5120-EI Series Ethernet Switches
Installation Manual.
Combo Port Configuration
Introduction to Combo port
A Combo port can operate as either an optical port or an electrical port. Inside the device there is only
one forwarding interface. For a Combo port, the electrical port and the corresponding optical port are
TX-SFP multiplexed. You can specify a Combo port to operate as an electrical port or an optical port.
That is, a Combo port cannot operate as both an electrical port and an optical port simultaneously.
When one is enabled, the other is automatically disabled.
Configuring Combo port state
Follow these steps to configure the state of a Combo port:
To do… Use the command… Remarks
Enter system view
system-view
—
Enter Ethernet interface view
interface interface-type
interface-number
—
Enable a specified Combo port
undo shutdown
Optional
By default, of the two ports in a
Combo port, the one with a
smaller port ID is enabled.
