1-4
z Currently, port security supports two authentication methods: 802.1X and MAC authentication.
Different port security modes employ different authentication methods or different combinations of
authentication methods.
z The maximum number of users a port supports is the lesser of the maximum number of secure
MAC addresses or the maximum number of authenticated users the security mode supports. For
example, in userLoginSecureExt mode, the maximum number of users a port supports is the lesser
of the maximum number of secure MAC addresses configured or the maximum number of users
that 802.1X supports.
These security mode naming rules may help you remember the modes:
z userLogin specifies port-based 802.1X authentication.
z macAddress specifies MAC address authentication.
z Else specifies that the authentication method before Else is applied first. If the authentication fails,
the protocol type of the authentication request determines whether to turn to the authentication
method following the Else.
z In a security mode with Or, the protocol type of the authentication request determines which
authentication method is to be used. However, 802.1X authentication is preferred by wireless
users.
z userLogin with Secure specifies MAC-based 802.1X authentication.
z Ext indicates allowing multiple 802.1X users to be authenticated and get online. A security mode
without Ext allows only one 802.1X user to be authenticated and get online.
Port Security Configuration Task List
Complete the following tasks to configure port security:
Task Remarks
Enabling Port Security Required
Setting the Maximum Number of Secure MAC Addresses Optional
Setting the Port Security Mode Required
Configuring NTK
Configuring Intrusion Protection
Configuring Port Security Features
Configuring Trapping
Optional
Choose one or
more features as
required.
Configuring Secure MAC Addresses Optional
Ignoring Authorization Information from the Server Optional
