3-4
TFTP Client Configuration Example
Single Device Upgrade
Network requirements
z As shown in Figure 3-2, use a PC as the TFTP server and Device as the TFTP client. Their IP
addresses are 1.2.1.1/16 and 1.1.1.1/16 respectively. An available route exists between Device
and PC.
z Device downloads a startup file from PC for upgrading and uploads a configuration file named
config.cfg to PC for backup.
Figure 3-2 Smooth upgrading using the TFTP client function
Configuration procedure
1) Configure PC (TFTP Server), the configuration procedure is omitted.
z On the PC, enable the TFTP server
z Configure a TFTP working directory
2) Configure Device (TFTP Client)
If the available memory space of the device is not enough, use the fixdisk command to clear the
memory or use the delete /unreserved file-url command to delete the files not in use and then perform
the following operations.
# Enter system view.
<Sysname> system-view
# Download application file newest.bin from PC.
<Sysname> tftp 1.2.1.1 get newest.bin
# Upload a configuration file config.cfg to the TFTP server.
<Sysname> tftp 1.2.1.1 put config.cfg configback.cfg
# Specify newest.bin as the main startup file to be used at the next startup.
<Sysname> boot-loader file newest.bin main
# Reboot the device and the software is upgraded.
<Sysname> reboot
