1-5
z Configure VLAN 20 for flush update.
Configuration procedure
<Sysname> system-view
[Sysname] vlan 20
[Sysname-vlan20] quit
[Sysname] interface gigabitethernet 1/0/1
[Sysname-GigabitEthernet1/0/1] undo stp enable
[Sysname-GigabitEthernet1/0/1] port link-type trunk
[Sysname-GigabitEthernet1/0/1] port trunk permit vlan 20
[Sysname-GigabitEthernet1/0/1] quit
[Sysname] interface gigabitethernet 1/0/2
[Sysname-GigabitEthernet1/0/2] undo stp enable
[Sysname-GigabitEthernet1/0/2] port link-type trunk
[Sysname-GigabitEthernet1/0/2] port trunk permit vlan 20
[Sysname-GigabitEthernet1/0/2] quit
[Sysname] smart-link group 1
[Sysname-smlk-group1] protected-vlan reference-instance 0 to 8
[Sysname-smlk-group1] port gigabitethernet1/0/1 master
[Sysname-smlk-group1] port gigabitethernet1/0/2 slave
[Sysname-smlk-group1] flush enable control-vlan 20
Configuring an Associated Device
The active and standby links in a smart link group may traverse multiple devices between the Smart
Link device and the destination device. For Smart Link to work, you need to enable all the ports on the
way to the destination to process the flush messages sent from the smart link device.
For example, as all the numbered ports on Device A, B, and D in
Figure 1-1 are on the way of the active
and standby links from Device C and E to Device A, you need to enable the ports to process flush
messages received from the control VLAN configured on Device C and E.
Configuring an Associated Device
Follow these steps to configure an associated device:
To do… Use the command… Remarks
Enter system view
system-view
—
Enter Ethernet interface view or
Layer-2 aggregate interface
view
interface interface-type
interface-number
—
Configure the control VLAN for
receiving flush messages
smart-link flush enable
[ control-vlan vlan-id-list ]
Required
No control VLAN exists for
receiving flush messages of
Smart Link by default.
