1-24
[Device] interface GigabitEthernet 1/0/2
[Device-GigabitEthernet1/0/2] dot1x
# Set the port access control method to portbased.
[Device-GigabitEthernet1/0/2] dot1x port-method portbased
# Set the port access control mode to auto.
[Device-GigabitEthernet1/0/2] dot1x port-control auto
[Device-GigabitEthernet1/0/2] quit
# Create VLAN 10.
[Device] vlan 10
[Device-vlan10] quit
# Specify port GigabitEthernet 1/0/2 to use VLAN 10 as its guest VLAN.
[Device] dot1x guest-vlan 10 interface GigabitEthernet 1/0/2
You can use the display current-configuration or display interface GigabitEthernet 1/0/2 command
to view your configuration. You can also use the display vlan 10 command in the following cases to
verify whether the configured guest VLAN functions:
z When no users log in.
z When a user goes offline.
After a user passes the authentication successfully, you can use the display interface
GigabitEthernet 1/0/2 command to verity that port GigabitEthernet 1/0/2 has been added to the
assigned VLAN 5.
ACL Assignment Configuration Example
Network requirements
As shown in Figure 1-14, a host is connected to port GigabitEthernet 1/0/1 of the device and must pass
802.1X authentication to access the Internet.
z Configure the RADIUS server to assign ACL 3000.
z Enable 802.1X authentication on port GigabitEthernet 1/0/1 of the device, and configure ACL 3000.
After the host passes 802.1X authentication, the RADIUS server assigns ACL 3000 to port
GigabitEthernet 1/0/1. As a result, the host can access the Internet but cannot access the FTP server,
whose IP address is 10.0.0.1.
Figure 1-14 Network diagram for ACL assignment
