5-2
To do… Use the command… Remarks
Specify the service types for
the local user
service-type telnet
Optional
By default, no service is
authorized to a user.
Start the Web server
ip http enable
Required
Execute this command in
system view.
Displaying Web Users
After the above configurations, execute the display command in any view to display the information
about Web users, and thus to verify the configuration effect.
Table 5-2 Display information about Web users
To do… Use the command…
Display information about Web users
display web users
Configuration Example
Step 1: Log in to the switch through the console port and assign an IP address to the management
VLAN interface of the switch. By default, VLAN 1 is the management VLAN.
z Connect to the console port. Refer to section Setting Up the Connection to the Console Port.
z Execute the following commands in the terminal window to assign an IP address to the
management VLAN interface of the switch.
# Configure the IP address of the management VLAN interface to be 10.153.17.82 with the mask
255.255.255.0.
<Sysname> system-view
[Sysname] interface vlan-interface 1
[Sysname-Vlan-interface1] ip address 10.153.17.82 255.255.255.0
Step 2: Configure the user name and the password for the Web-based network management system.
# Configure the user name to be admin.
[Sysname] local-user admin
# Set the password to admin.
[Sysname-luser-admin] password simple admin
Step 3: Establish an HTTP connection between your PC and the switch, as shown in the following
figure.
Figure 5-1 Establish an HTTP connection between your PC and the switch
