[DeviceE-smlk-group1] port gigabitethernet1/0/2 master
[DeviceE-smlk-group1] port gigabitethernet1/0/1 slave
# Configure VLAN 1 as the transmit control VLAN.
[DeviceE-smlk-group1] flush enable
3) Configuration on Device B
# Configure VLAN 1 as the receive control VLAN for GigabitEthernet 1/0/1, GigabitEthernet 1/0/2, and
GigabitEthernet 1/0/3.
<DeviceB> system-view
[DeviceB] interface gigabitethernet 1/0/1
[DeviceB-GigabitEthernet1/0/1] smart-link flush enable
[DeviceB-GigabitEthernet1/0/1] quit
[DeviceB] interface gigabitethernet 1/0/2
[DeviceB-GigabitEthernet1/0/2] smart-link flush enable
[DeviceB-GigabitEthernet1/0/2] quit
[DeviceB] interface gigabitethernet 1/0/3
[DeviceB-GigabitEthernet1/0/3] smart-link flush enable
4) Configuration on Device D
# Configure VLAN 1 as the receive control VLAN for GigabitEthernet 1/0/1, GigabitEthernet 1/0/2, and
GigabitEthernet 1/0/3.
<DeviceD> system-view
[DeviceD] interface gigabitethernet 1/0/1
[DeviceD-GigabitEthernet1/0/1] smart-link flush enable
[DeviceD-GigabitEthernet1/0/1] quit
[DeviceD] interface gigabitethernet 1/0/2
[DeviceD-GigabitEthernet1/0/2] smart-link flush enable
[DeviceD-GigabitEthernet1/0/2] quit
[DeviceD] interface gigabitethernet 1/0/3
[DeviceD-GigabitEthernet1/0/3] smart-link flush enable
5) Configuration on Device A
# Configure VLAN 1 as the receive control VLAN for GigabitEthernet 1/0/1, GigabitEthernet 1/0/2, and
GigabitEthernet 1/0/3.
<DeviceA> system-view
[DeviceA] interface gigabitethernet 1/0/1
[DeviceA-GigabitEthernet1/0/1] smart-link flush enable
[DeviceA-GigabitEthernet1/0/1] quit
[DeviceA] interface gigabitethernet 1/0/2
[DeviceA-GigabitEthernet1/0/2] smart-link flush enable
After completing the configuration, you can use the display command to verify the smart link
configuration and view flush message statistics.
Multiple Smart Link Groups Load Sharing Configuration Example
Network requirements
As shown in Figure 1-3:
