H3C S5120-EI Series User Manual

1-6
Configuring an Aggregation Group
z The following ports cannot be assigned to an aggregation group: Stack ports, RRPP-enabled ports,
MAC address authentication-enabled ports, port security-enabled ports, IP source guard-enabled
ports, and 802.1x-enabled ports.
z You are recommended not to assign reflector ports of port mirroring to an aggregation group. For
details about reflector ports, refer to Port Mirroring Configuration in the Access Volume.
Configuring a Static Aggregation Group
Follow these steps to configure a Layer 2 static aggregation group:
To do... Use the command... Remarks
Enter system view
system-view
—
Create a Layer 2
aggregate interface and
enter the Layer 2
aggregate interface view
interface bridge-aggregation
interface-number
Required
When you create a Layer 2
aggregate interface, a Layer 2
static aggregation group
numbered the same is created
automatically.
Exit to system view
quit
—
Enter Ethernet interface
view
interface interface-type
interface-number
Assign the Ethernet
interface to the
aggregation group
port link-aggregation group number
Required
Repeat the two steps to assign
multiple Ethernet interfaces to
the aggregation group.
z Removing a Layer 2 aggregate interface also removes the corresponding aggregation group. At
the same time, the member ports of the aggregation group, if any, leave the aggregation group.
z To guarantee a successful static aggregation, ensure that the ports at the two ends of each link to
be aggregated are consistent in the selected/unselected state.
