H3C S5120-EI Series User Manual

5-5
Configuration Example
Network requirements
Configure GigabitEthernet1/0/1 to adopt SP queue scheduling algorithm.
Configuration procedure
# Enter system view.
<Sysname> system-view
# Configure an SP queue for GigabitEthernet1/0/1 port.
[Sysname] interface GigabitEthernet 1/0/1
[Sysname-GigabitEthernet1/0/1] qos sp
Configuring a WRR Queue
Configuration Procedure
Follow these steps to configure WRR queues:
To do… Use the command… Remarks
Enter system view
system-view
—
Enter port
view
interface interface-type
interface-number
Enter port
view or
port group
view
Enter port
group
view
port-group manual
port-group-name
Perform either of the two operations.
The configuration performed in Ethernet
interface view applies to the current port
only. The configuration performed in port
group view applies to all the ports in the
port group
Enable WRR on the
port
qos wrr
Optional
Enabled by default.
Configure WRR queue
scheduling
qos wrr queue-id group
group-id weight
schedule-value
Required
By default, all the ports adopt the WRR
queue scheduling algorithm, with the
weight values assigned to queue 0 through
queue 7 being 1, 2, 3, 4, 5, 9, 13, and 15.
Configuration Example
Network requirements
Configure WRR queue scheduling algorithm on GigabitEthernet1/0/1, and assign weight 1, 2, 4, 6, 8, 10,
12, and 14 to queue 0 through queue 7.
Configuration procedure
# Enter system view.
<Sysname> system-view
# Configure the WRR queues on GigabitEthernet1/0/1 port.
[Sysname] interface GigabitEthernet 1/0/1
[Sysname-GigabitEthernet1/0/1] qos wrr
[Sysname-GigabitEthernet1/0/1] qos wrr 0 group 1 weight 1
