1-7
Configuring a Dynamic Aggregation Group
Follow these steps to configure a Layer 2 dynamic aggregation group:
To do... Use the command... Remarks
Enter system view
system-view
—
Set the system LACP
priority
lacp system-priority
system-priority
Optional
By default, the system LACP priority is
32768.
Changing the system LACP priority
may affect the selected/unselected
state of the ports in the dynamic
aggregation group.
Create a Layer 2
aggregate interface and
enter the Layer 2
aggregate interface view
interface
bridge-aggregation
interface-number
Required
When you create a Layer 2 aggregate
interface, a Layer 2 static aggregation
group numbered the same is created
automatically.
Configure the
aggregation group to
work in dynamic
aggregation mode
link-aggregation mode
dynamic
Required
By default, an aggregation group
works in static aggregation mode.
Exit to system view
quit
—
Enter Layer 2 Ethernet
interface view
interface interface-type
interface-number
Assign the Ethernet
interface to the
aggregation group
port link-aggregation group
number
Required
Repeat the two steps to assign multiple
Ethernet interfaces to the aggregation
group.
Assign the port a LACP
priority
lacp port-priority
port-priority
Optional
By default, the LACP priority of a port is
32768.
Changing the LACP priority of a port
may affect the selected/unselected
state of the ports in the dynamic
aggregation group.
z Removing a dynamic aggregate interface also removes the corresponding aggregation group. At
the same time, the member ports of the aggregation group, if any, leave the aggregation group.
z To guarantee a successful dynamic aggregation, ensure that the peer ports of the ports
aggregated at one end are also aggregated. The two ends can automatically negotiate the selected
state of the ports.
Configuring an Aggregate Interface
You can perform the following configurations for an aggregate interface:
z Configuring the Description of an Aggregate Interface
