H3C S5120-EI Series - Console Port Login Configuration

2-3
Figure 2-4 Set port parameters terminal window
z Turn on the switch. The user will be prompted to press the Enter key if the switch successfully
completes POST (power-on self test). The prompt (such as <H3C>) appears after the user presses
the Enter key.
z You can then configure the switch or check the information about the switch by executing
commands. You can also acquire help by type the ? character. Refer to the following chapters for
information about the commands.
Console Port Login Configuration
Common Configuration
Table 2-2 lists the common configuration of Console port login.
Table 2-2 Common configuration of Console port login
Configuration Description
Enter system view
system-view
—
Enter AUX user interface view user-interface aux 0 —
Baud rate speed speed-value
Optional
The default baud rate is 9,600
bps.
Check mode
parity { even | mark |
none | odd | space }
Optional
By default, the check mode of
the Console port is set to
“none”, which means no check
bit.
Console port
configuration
Stop bits stopbits { 1 | 1.5 | 2 }
Optional
The default stop bits of a
Console port is 1.
