H3C S5120-EI Series User Manual

1-7
To do... Use the command... Remarks
Configure a remote MEP for a
MEP in the same service
instance
cfd remote-mep
remote-mep-id
service-instance instance-id
mep mep-id
Required
No remote MEP is configured
for a MEP by default.
Enable the MEP
cfd mep service-instance
instance-id mep mep-id
enable
Required
Disabled by default
Configuring MIP Generation Rules
As functional entities in a service instance, MIPs deal with LBM and LTM messages.
MIPs are generated on each port according to some rules. You can choose appropriate MIP generation
rules based on your network design.
Follow these steps to configure the rules for generating MIPs:
To do... Use the command... Remarks
Enter system view
system-view
—
Configure the rules for
generating MIPs
cfd mip-rule { explicit |
default } service-instance
instance-id
Required
By default, neither the MIPs nor the rules
for generating MIPs are configured.
MIPs are generated on each port automatically according to the rules specified in the cfd mip-rule
command. If a port has no MIP, the system will check the MAs in each MD (from low to high levels), and
follow the rules in
Table 1-1 to create or not create MIPs (within a single VLAN):
Table 1-1 Rules for generating MIP
MIP exists on low
level MA
The cfd mip-rule
command is
configured as
MEP exists on low
level MA
Create MIP or not
Yes — — No
No No
Explicit
Yes Yes
No
Default — Yes
Each of the following actions or cases can cause MIPs to be created or deleted after you have
configured the cfd mip-rule command:
z Enabling CFD (use the cfd enable command)
z Creating or deleting the MEPs on a port
z Changes occur to the VLAN attribute of a port
z The rule specified in the cfd mip-rule command changes
Configuring CC on MEPs
After the CC function is configured, MEPs can send CCMs mutually to check the connectivity between
them.
