1-5
For static and dynamic aggregation modes:
z In an aggregation group, the port to be a selected port must be the same as the reference port in
port attributes, and class-two configurations. To keep these configurations consistent, you should
configure the port manually.
z Because changing a port attribute or class-two configuration setting of a port may cause the select
state of the port and other member ports to change and thus affects services, you are
recommended to do that with caution.
Load Sharing Mode of an Aggregation Group
The link aggregation groups created on the S5120-EI series Ethernet switches always operate in load
sharing mode, even when they contain only one member port
Link Aggregation Configuration Task List
Complete the following tasks to configure link aggregation:
Task Remarks
Configuring a Static Aggregation Group
Configuring an
Aggregation Group
Configuring a Dynamic Aggregation Group
Required
Perform either of the tasks
Configuring the Description of an Aggregate
Interface
Optional
Enabling LinkUp/LinkDown Trap Generation
for an Aggregate Interface
Optional
Configuring an
Aggregate Interface
Shutting Down an Aggregate Interface Optional
Configuring a Load Sharing Mode for Load-Sharing Link Aggregation
Groups
Optional
