H3C S5120-EI Series User Manual

1-19
To do… Use the command… Remarks
Create a Track object and
associate it with the
specified collaboration
object of the NQA test group
track entry-number nqa entry
admin-name operation-tag reaction
item-num
Required
Not created by default.
z You cannot modify the content of a reaction entry using the reaction command after the
collaboration object is created.
z The collaboration function is not supported in a UDP jitter or voice test.
Configuring Trap Delivery
Traps can be sent to the network management server when test is completed, test fails or probe fails.
Configuration prerequisites
Before configuring trap delivery, you need to configure the destination address of the trap message with
the snmp-agent target-host command, create an NQA test group, and configure related parameters.
For the introduction to the snmp-agent target-host command, see SNMP Commands in the System
Volume.
Configuring trap delivery
Follow these steps to configure trap delivery:
To do… Use the command… Remarks
Enter system view
system-view
—
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Enter test type view of the test
group
type { dhcp | dlsw | ftp | http |
icmp-echo | snmp | tcp |
udp-echo | udp-jitter | voice }
—
Configure to send traps to
network management server
under specified conditions
reaction trap { probe-failure
consecutive-probe-failures |
test-complete | test-failure
cumulate-probe-failures }
Optional
No traps are sent to the
network management server by
default.
Only the reaction trap test-complete command is supported in a voice test, namely, in a voice test,
traps are sent to the NMS only if the test succeeds.
