H3C S5120-EI Series User Manual

1-14
To do… Use the command… Remarks
Configure the destination port
destination port
port-number
Required
By default, no destination port
number is configured for a test
operation.
The destination port number must
be consistent with port number of
the listening service configured on
the NQA server.
Configure the source IP
address of a probe request in a
test operation
source ip ip-address
Optional
By default, no source IP address is
specified.
The source IP address must be that
of an interface on the device and the
interface must be up. Otherwise, the
test will fail.
Configure common optional
parameters
See
Configuring Optional
Parameters Common to an
NQA Test Group
Optional
Configuring a UDP Echo Test
A UDP echo test is used to test the connectivity and roundtrip time of a UDP echo packet from the client
to the specified UDP port on the NQA server.
Configuration prerequisites
A UDP echo test requires cooperation between the NQA server and the NQA client. The UDP listening
function needs to be configured on the NQA server before the UDP echo test. For the configuration of
the UDP listening function, see
Configuring the NQA Server.
Configuring a UDP echo test
Follow these steps to configure a UDP echo test
To do… Use the command… Remarks
Enter system view
system-view
—
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Configure the test type as UDP
echo and enter test type view
type udp-echo
Required
Configure the destination
address for a test operation
destination ip
ip-address
Required
By default, no destination IP address is
configured for a test operation.
The destination address must be the IP
address of the listening service
configured on the NQA server.
