1-13
[Switch-ui-vty0-4] protocol inbound ssh
[Switch-ui-vty0-4] quit
# Create local user client001, and set the user command privilege level to 3
[Switch] local-user client001
[Switch-luser-client001] password simple aabbcc
[Switch-luser-client001] service-type ssh
[Router-luser-client001] authorization-attribute level 3
[Switch-luser-client001] quit
# Specify the service type for user client001 as Stelnet, and the authentication mode as password.
This step is optional.
[Switch] ssh user client001 service-type stelnet authentication-type password
2) Configure the SSH client
There are many kinds of SSH client software, such as PuTTY, and OpenSSH. The following is an
example of configuring SSH client using Putty Version 0.58.
# Establish a connection with the SSH server
Launch PuTTY.exe to enter the following interface. In the Host Name (or IP address) text box, enter
the IP address of the server (192.168.1.40).
