H3C S5120-EI Series User Manual

1-18
Likewise, to save the private key, click Save private key. A warning window pops up to prompt you
whether to save the private key without any protection. Click Yes and enter the name of the file for
saving the key (private in this case).
Figure 1-7 Generate a client key pair 4)
After generating a key pair on a client, you need to transmit the saved public key file to the server
through FTP or TFTP and have the configuration on the server done before continuing configuration of
the client.
# Specify the private key file and establish a connection with the SSH server
Launch PuTTY.exe to enter the following interface. In the Host Name (or IP address) text box, enter
the IP address of the server (192.168.1.40).
Figure 1-8 SSH client configuration interface 1)
