Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 173 ProView 7000 v.2.4, Rev. A
■ LCD Contrast – sets the front panel LCD contrast.
Valid range is 01 – 31, where 1 is lowest and 31 is highest constrast.
■ Reset Unit – enables a warm reset on the ProView 7000.
Selecting the Reset Device option, starts a three step procedure which, when completed,
reboots the device.
■ Restore to Defaults – Use this menu to restore the default configuration. IP management
addresses are not changed.
5.2.8.1 Management Port Configuration
The Ethernet menu allows setting the Ethernet management port parameters.
To access the Unit Ethernet Management Port menu:
❖ Navigate to Root > Unit > Management Port.
Each option in the menu leads to value setup screen (i.e., selecting the option displays either
an edit value screen - to set a new value or a select value screen with radio button options).
The Management Port Configuration menu provides the following options:
■ IP Configuration – manages the IP configuration of the GbE port. The sub-menu manages
the following parameters:
❑ IP Address – sets the IP address of the port.
❑ Subnet mask – sets the network subnet mask address for the port.
❑ Default Gateway – sets the network default gateway address. This is the address of a
local IP router on the same network as the ProView 7000, which is used to forward
traffic beyond the local network.
■ MAC Address – displays the media access control (MAC) address for the device.
■ Auto Negotiation – activates the port autonegotiation capability.
Radio Button options: On and Off (Selection is not enabled. Always On).
■ PHY Speed – selects the physical layer speed.
Radio Button options: 100 and 1000 [Mbps] (Selection is not enabled. Set to 100 Mbps).
Management Port
1 IP Configuration
2 MAC Address 00:0a:35:00:23:01
3 Auto Negotiation „ On
4 PHY Speed „ 100
