Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 174 ProView 7000 v.2.4, Rev. A
5.2.8.2 Hardware Inventory Display Menu
The ProView 7000 allows monitoring ProView 7000 version parameters.
To access the ProView 7000 Version Status menu:
❖ Navigate Root > Unit > HW Inventory.
The Hardware Inventory sub-menu contains the following items:
■ Platform – The Platform Properties sub-menu displays the following information:
❑ Part Number
❑ Serial number
■ Main Board – The Main Board Properties sub-menu displays the following information:
❑ Part Number
❑ Serial Number
❑ Main FPGA Version
❑ Auxiliary FPGA Version
■ Front End Card – The Front End Card properties sub-menu displays the following
information on the front end unit installed in the device:
❑ Part Number
❑ Revision Number
❑ Serial Number
❑ FPGA Version
❑ DVB-S2 Demodulator Version
❑ DVB-S Demodulator Version
■ Bottom Option Card – The Bottom Options card properties sub-menu displays the
following information:
❑ Part Number
❑ Revision Number
❑ Serial Number
❑ Decoder SW Version
NOTE: The Top Card and/or Bottom Card information is displayed only when the respective optional
card is installed.
HW Inventory
1 Platform
2 Main Board
3 Front End Card
4 Bottom Option Card
