Chapter 3 Configuration and Monitoring How to Configure and Monitor the ProView 7000
© 2011 Harmonic Inc. 29 ProView 7000 v.2.4, Rev. A
f Select Apply Changes.
gNavigate
Root > GbE > GbE Port (1 or 2) > Admin Status.
h Set the Admin Status to Up.
iNavigate
Root > GbE > Socket Configuration > Socket In > Socket (no.) >
Traffic Parameters
.
j Configure the IP Address Type, UDP Port and IP Address if you are using Multicast.
kNavigate
Root > GbE > Socket Configuration > Socket In > Socket (no.).
l Configure the Socket De-Jittering Mode, SSM and Socket Admin Status.
3. If the output stream is sent to IP, perform the following to configure a GbE output port:
aNavigate Root > Unit > GbE Mode (In/Out).
bSet the GbE mode to
Out.
The device reboots.
cNavigate
Root > GbE > GbE Port (1 or 2) > IP Configuration.
d Configure the IP Address, Subnet Mask and Default Gateway.
e Select
Apply Port Changes.
f Select
Apply Changes.
gNavigate
Root > GbE > GbE Port (1 or 2) > Admin Status.
h Set the Admin Status to Up.
iNavigate
Root > GbE > Socket Configuration > Socket Out > Socket (no.).
j Configure the Destination IP Address and the Destination UDP Port.
k Set the Socket Status to Up.
4. If you wish to descramble, you must associate the CAM to the multiplex:
aNavigate Root > CAM > CAM (1 or 2) > CAM Association.
b Select a multiplex, TS1, TS2, TS3 or TS4.
The descrambling mode default is Selective, you can change the mode to Full.
5. To access the CAM MMI menu, select CAM MMI.
6. Select a DVB-S/S2 input port:
aNavigate Root > Routing and Descrambling > TS (no.) > Input Selection.
b Select an input port for the received transport stream (Options: SAT (1–4), ASI (1–4)).
7. Select Input Type, (Options: MPEG and DVB). This also sets the respective PSI/SI tables for
the output stream.
NOTE: The default option for stream type is DVB. For ATSC systems, set the stream type to MPEG.
8. To configure the multiplex output:
aNavigate Root > Routing and Descrambling > TS (no.) > Output Selection.
b Select one or more outputs for the received transport stream (Options: ASI (1–2),
Socket (1–4).) The four sockets are virtual and must be associated to a physical GbE
port.
c Select
Enable in each output sub-menu that you select.
