Chapter 3 Configuration and Monitoring How to Configure and Monitor the ProView 7000
© 2011 Harmonic Inc. 30 ProView 7000 v.2.4, Rev. A
NOTE: In this mode, stream information is not processed and output bit rate is identical to input bit
rate.
dNavigate Root > Routing and Descrambling > TS (no.) > Activation.
e Select
Enable.
9. To select a program for descrambling:
aNavigate Root > Routing Descrambling > TS (no.) > Descrambling.
A list of all input programs received displays.
Program name, program ID, program type and program scrambling state display.
b Select a program for descrambling.
c Select CAM Selection.
d Select CAM 1 or CAM 2 to associate the program to it.
Repeat steps 6 to 9 for each multiplex that you wish to use (1–4).
10. Navigate Root > Decoding > Configuration> Input Selection.
11. Select a multiplex, 1,2, 3 or 4, for input.
12. Set the Service Selection Mode:
aNavigate Root > Decoding > Configuration > Service Selection Mode.
b Select
Program Selection.
13. Navigate Root > Decoding > Configuration> Programs.
The Programs menu displays a list of programs available on the input transport stream
and enables you to select the program to be decoded.
The screen displays the program name if the input stream provides an SDT table, the
program ID (decimal number), the program type (TV or Radio) and the program mode
(CAS/scrambled or FTA/free to air).
Only one program can be selected (radio button selection).
Descrambling
1 BBC, ID:4301, TV, CAS
2 CNN, ID:4302, TV, CAS
3 IBA 2 ID:4308, AUDIO, FTA
4 MI-TV, ID:8025, TV, FTA
Name ID Type
Mode
1 ƒ BBC 4301 TV CAS
2 ‚ CNN 4302 TV CAS
3 ‚ IBA 2 4308 AUDIO FTA
