Chapter 4 Element Management System (EMS) Device Explorer
© 2011 Harmonic Inc. 71 ProView 7000 v.2.4, Rev. A
4.4.2.2 Input Tables Management
Click the Tables branch in the Multiplex Input box to display all the tables related to the
multiplex input and the type of information provided by the table.
The Input Tables branch provides access to the following MPEG PSI and DVB PSI/SI tables
related to the multiplexed stream:
■ Program Association Table (PAT) for the stream
■ Conditional Access Table (CAT) and the specific Entitlement Management Messages (EMM)
in the CAT
■ Program Map Tables (PMTs) for each multiplex program
■ Network Information Table (NIT)
■ Service Description Tables (SDTs)
■ Event Information Table (EIT)
■ Time and Date Table (TDT/TOT) associated with the stream
NOTE: The displayed tables are managed by the stream type defined (MPEG or DVB). The property of the
various input tables in the multiplexed input stream is detailed in 4.5.3.5 Input Tables Properties.
