188
Installation
Input - Setting before shipment
Mark Description Default settings Available input codes Terminals
I1 Input 1
i - 08
(Demand ON/OFF 1)
i - 00~17
(Except i - 07/12)
I1, L1
on TB3
Closed/Open
220-240V ~ 50/60Hz
I2 Input 2
i - 13
(Cycle 1 and 2 ECO mode)
i - 00~17
(Except i - 07/12)
I2, +12V
on TB4
Closed/Open 12V DC
I3 Input 3
i - 00
(No function)
i - 00~17
(Except i - 07/12)
I3, L3
on TB3
Closed/Open
220-240V ~ 50/60Hz
I4 Input 4
i - 04
(Solar in)
i - 00~17
(Except i - 07/12)
I4, L3
on TB3
Closed/Open
220-240V ~ 50/60Hz
I5 Input 5
i - 02
(Smart Act.)
i - 00~17
(Except i - 07/12)
I5, +12V
on TB4
Closed/Open 12V DC
I6 Input 6
i - 06
(DHW Boost)
i - 00~17
(Except i - 07/12)
I6, L3
on TB3
Closed/Open
220-240V ~ 50/60Hz
I7 Input 7
i - 07
(Power meter 1)
i - 00~17
I7, COM
on TB4
Closed/Open 12V DC
I8 Input 8
i - 12
(Power meter 2)
i - 00~17
I8, COM
on TB4
Closed/Open 12V DC
I9 Input 9
i - 09
(Demand ON/OFF 2)
i - 00~17
(Except i - 07/12)
I9, +12V
on TB4
Closed/Open 12V DC
I10 Input 10
i - 00
(No function)
i - 00~17
(Except i - 07/12)
I10, +12V
on TB4
Closed/Open 12V DC
I11 Input 11
i - 00
(No function)
i - 00~17
(Except i - 07/12)
I11, +12V
on TB4
Closed/Open 12V DC
Input - All input codes descriptions:
Input codes Mark Description
i - 00 No Function -
i - 02
Smart Act./
SG Ready Input 1
This function must be used to stop or limit the heat pump and Auxiliary electric heater when restricted
the heat pump and Auxiliary electric heater during time of peak electricity demand.
operating modes.
i - 03
Swimming pool Demand
ON/OFF
SWP. Switch ON/OFF of SWP can also be controlled by master controller.
Closed: Start SWP operation (Switch ON and Demand ON) Open: Stop SWP operation (Switch OFF
and Demand OFF).
i - 04 Solar in
In case of combining Unit with solar panels, this input is used as a feedback for solar station ready
operation.
Closed: Solar in ON to trigger solar pump operation ON Open: Solar in OFF to trigger solar pump
operation OFF.
i - 05 Forced Heating/Cooling
Heating/cooling can be changed by an input of an external contact signal. Heating/cooling can also
be changed over by master controller.
Closed: Heating mode Open: Cooling mode.
i - 06 DHW Boost
With this function enabled, it is possible to request a heating up of the DHW when user requires an
instantaneous delivery of DHW. Triggering input signal can also Switch ON DHW.
i - 07 Power meter 1
Input used as kW/h pulse count for Energy data recording, used to count energy data or the total
energy data.
i - 08 Demand ON/OFF 1
and selected as room thermostat.
Closed: Corresponding room thermostat Switch ON and Thermo ON. Open: Corresponding room
thermostat Switch OFF and Thermo OFF.
Corresponding room thermostat can also be Switch ON/OFF by Rooms function on Master controller.
i - 09 Demand ON/OFF 2
