Hisense AHM-080HCDSAA - Page 211

190
Installation
Output - Setting before shipment
Mark Description Default settings Available output codes Terminals 
O1 Output 1
o - 01
(3WV SWP)
o - 00 ~ 29
(Except o - 02/08/17/21)
Power
supply
L2, N6
on TB3
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
Signal
line
O1
on TB3
O2 Output 2
o - 02
(WP3)
o - 00 ~ 29
(Except o - 17)
O2, N2
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O3 Output 3
o - 03
(Boiler combination)
o - 00 ~ 29
(Except o - 02/08/17/21)
O3
on TB2
Free voltage
Max. 1.0A
O4 Output 4
o - 04
(Solar out)
o - 00 ~ 29
(Except o - 02/08/17/21)
O4
on TB3
Free voltage
Max. 1.0A
O5 Output 5
o - 17
(DHW Electric Heater)
o - 00 ~ 29
HL, HN
on TB1
ON/OFF
220-240V ~ 50/60Hz
Max. 15A
O6 Output 6
o - 18
(3WV DHW)
o - 00 ~ 29
(Except o - 02/08/17/21)
Power
supply
L2, N6
on TB3
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
Signal
line
O6
on TB3
O7 Output 7
o - 19
(Mixing valve Close)
o - 00 ~ 29
(Except o - 02/08/17/21)
O7, N4
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O8 Output 8
o - 20
(Mixing valve Open)
o - 00 ~ 29
(Except o - 02/08/17/21)
O8, N4
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O9 Output 9
o - 21
(WP2)
o - 00 ~ 29
(Except o - 17)
O9, N1
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O10 Output 10
o - 22
(3WV Cooling)
o - 00 ~ 29
(Except o - 02/08/17/21)
Power
supply
L1, N5
on TB3
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
Signal
line
O10
on TB3
O11 Output 11
o - 08
(WP1)
o - 00 ~ 29
(Except o - 17)
O11, N1
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O12 Output 12
o - 23
(Act1)
o - 00 ~ 29
(Except o - 02/08/17/21)
O12, N2
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O13 Output 13
o - 24
(Act2)
o - 00 ~ 29
(Except o - 02/08/17/21)
O13, N3
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O14 Output 14
o - 25
(Act3)
o - 00 ~ 29
(Except o - 02/08/17/21)
O14, N3
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
O15 Output 15
o - 26
(Act4)
o - 00 ~ 29
(Except o - 02/08/17/21)
O15, N4
on TB2
ON/OFF
220-240V ~ 50/60Hz
Max. 1.0A
