HONDA
CB400T
REAR
WHEEL
/BRAKE-/
13.
SUSPENSION
r--.
SERVICE INFORMATION 14-1
TROUBLESHOOTING 14-2
REAR WHEEL
REMOVAL1
DISASSEMBLY/ASSEMBLY 14-4
FINAL DRIVEN SPROCKET 14-6
REAR BRAKE PANEL 14-7
REAR WHEEL INSTALLATION 14-8
SHOCK ABSORBER 14-10
SWINGARM 14-11
BRAKE PEDAL 14-12
SERVICE INFORMATION
WORKING
PRACTICE
Do not remove the rivets, nuts and pins from the rim, spoke plates and hub, since they cannot be disassembled.
Do not ride on the rim or try to bend the wheel.
Handle with care since the rim
is
made of aluminum alloy.
SPECIAL TOOLS
Common Tools
BEARING DRIVER HANDLE
(Al
BEARING DRIVER OUTER (42
x
47 mml
BEARING DRIVER OUTER (52
x
55
mm)
BEARING DRIVER PILOT (20 mm)
BEARING DRIVER PILOT (17 mm)
REAR CUSHION COMPRESSOR
Date of
Issue: September, 1977
O
HONDA MOTOR CO., LTD.
