Honda CM400A - Stator Coil and Voltage Regulator Tests

HONDA
CB400T BATTERYICHARGING SYSTEM
STATOR COIL CONTINUITY
TEST
NOTE
It is not necessary to remove the stator
to make this
test.
Check the yellow leads to the AC generator
stator for continuity with each other. Replace
the stator if any yellow lead
is not continuous
with the others, or if any lead has continuity
to ground.
VOLTAGE REGULATOR1
RECTIFIER TEST
Check the
resistances between the leads with
an ohmmeter.
o not use a high voltage source such as I
insulation resistance tester since it
may damage the rectifier and give you
RESISTANCES IN NORMAL DIRECTION
GREEN LEAD AND ANY
YELLOW LEAD:
5-40
REDIWHITE LEAD AND ANY
YELLOW LEAD:
5-40 R
RESISTANCES IN REVERSE DIRECTION
REDIWHITE LEAD AND ANY
YELLOW LEAD:
2000R minimum
GREEN LEAD AND ANY
.
2 -
WHITE/ 4
t
PINK- i
BLUE GREEN
YELLOW LEAD:
2000R minimum
I
NORMAL DIRECTION
YELLOW
I ^ I
YELLOW
REDIWHITE
YELLOW
t
REVERSE DIRECTION
I
Date of Issue: September, 1977
o HONDA MOTOR co., LTD.
15-5
