Honda CM400A - Clutch;Oil Pump Contents

HONDA
CB400T
CLUTCH/OIL PUMP
SERVICE INFORMATION 8-1
1
1 TROBLESHOOTING 8-2 I
RIGHT CRANKCASE COVER REMOVAL 8-3
CLUTCH 8-3
OIL PUMP 8-1 1
OIL PRESSURE RELIEF VALVE
8-14
..
RIGHT CRANKCASE COVER INSTALLATION 8-15
SERVICE INFORMATION
WORKING PRACTICE
This section covers removal and installation of the clutch, oil pump and pressure relief valve, starting with the right crankcase
cover. Removal and installation of the gearshift linkage (Section
111, adjustment of the crankshaft balancer, and removal and
installation of the oil pressure switch should also be performed by first removing the right crankcase cover. All these operations
can be accomplished with the engine in the frame.
SPECIAL TOOLS
COMMON TOOLS
UNIVERSAL HOLDER 07725-001 01 01
LOCK NUT SOCKET WRENCH 07716-0020201
SPECIFICATIONS
.I
F
i
/
I
i
i
!
!
I
Oil pressure
relief valve
Date of Issue: July, 1979
o HONDA MOTOR co., LTD.
8- 1
Outer rotor-to-body clearance
Rotor-to-body clearance
Relief pressure
4.0-5.3
kg/cm2 (56.9-75.4 psi)
0.35 mm (0.014 in.)
0.10
mm (0.004 in.)
