104 H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015
Parts of the H-S81-HS System Cables
2.7 Cables
Possible connections according to module type:
Module PN Description
Termination
with Flat Cable
Termination
with Cable
S81-F3002-1 Module with 8 x 22VDC monitored inputs S81-T8001-1 S81-CCT1
S81-F3002-2 Module with 8 x 22VDC monitored inputs Not available S81-CCT1R
S81-F3002-3 Module with 8 x 12VDC monitored inputs S81-T8001-1 S81-CCT1
S81-F4001-1 Module with 1 x 4-20mA analog input S81-T8003-1 S81-CCT2
S81-F4001-2 Module with 1 x 4-20mA analog input Not available S81-CCT2R
S81-F4002-1 Module with 2 x 4-20mA analog inputs S81-T8003-1 S81-CCT7
S81-F4002-2 Module with 2 x 4-20mA analog inputs Not available S81-CCT7R
S81-F4003-1 Module with 8 x 4-20mA analog inputs S81-T8001-1 S81-CCT3
S81-F4003-2 Module with 8 x 4-20mA analog inputs Not available S81-CCT3R1
S81-F5001-1 Module with 8 x 500mA monitored outputs S81-T8006-1
S81-T8003-1
S81-CCT3
S81-F5001-2 Module with 8 x 500mA monitored outputs Not available S81-CCT3R
S81-F5002-1 Module with 16 x 250mA open collector outputs S81-T8007-1
S81-T8001-1
S81-CCT1
S81-F5003-1 Module with 8 x 500mA monitored outputs for sounders S81-T8001-1
S81-T8008-1
1
1 Combined with the S81-T8001-1 termination module
S81-CCT1
S81-T8008-1
S81-F5004-1 Module with 4 x 2A monitored outputs Not available S81-CCT4
S81-F5004-2 Module with 4 x 2A monitored outputs Not available S81-CCT4R
S81-F6001-1 Module for fire extinguishing systems EN-12094-1 Not available Not available
S81-F6002-1 Logic module Not available Not available
S81-F7002-1 Loop module with ESP protocol S81-T8003-1 S81-CCT4
S81-F7006-1 Modbus RTU Master/Slave module S81-T8003-1 S81-CCT6
S81-F7007-1 Loop module with SSP protocol S81-T8003-1 S81-CCT4
S81-F7008-1 Control module for scales S81-T8003-1 S81-CCT6
S81-F7009-1 Loop module with XP95/Discovery protocol S81-T8003-1 S81-CCT4
S81-F7010-1 Loop module with System Sensor protocol S81-T8003-1 S81-CCT4
