H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015 77
I/O modules Parts of the H-S81-HS System
Status Indications
The front panel includes 8 LEDs with the following functions:
Configuration
By using the configuration program ProS81, the following parameters can be set for each point of
the single devices, according to the relevant type:
The following measuring ranges, with the relevant thresholds, can be programmed for S81-Mod-
AI020, S81-Mod-AV010 analog modules:
LED Indication
Active (Red LED) Steady on if an input is under alarmed/activated condition
Disabled (Yellow LED) Steady on if an input or an output is disabled
Fault (Yellow LED) Flashing in case of Fault condition
Loop Fault (Yellow LED) Flashing in case of loop short circuit or open loop
Log on Fault (Yellow LED) Flashing in case of difference between the detected devices and the programmed ones.
Service (Yellow LED) Flashing in case of in case of smoke detectors with dirty lenses
TX Pol. (Green LED) It lights up every time data are transmitted from the module to loop devices.
RX Pol. (Green LED) It lights up every time data from loop devices are received
Parameter Type Mode
Operating mode Sensors Latching-NO, Latching-NC, Non-Latching-NO, Non-Latching-NC
Measuring range Sensors See table
Pre-alarm threshold Sensors According to the selected measuring range
Alarm threshold Sensors According to the selected measuring range
Type of indication Sensors Fire, Supervisory, Gas, Trouble, Hidden, Buzzer Only
Automatic alarm reset Sensors Yes/No
Operating mode Actuators Continuous-Normally Energized, Continuous-Normally De-energized,
Intermittent, Pulsing
Timing Actuators 1 to 255 seconds (only for pulsing and intermittent modes)
Enable/Disable status export to
Hosts
Sensors/Actuators No, TCP1, TCP2, RS232
Enable/Disable commands from
Hosts on the channel
Sensors/Actuators No, TCP1, TCP2, RS232
Measuring Range Pre-alarm Threshold Alarm Threshold
0-255 Bit 0-255 0-255
0-10 ppm 0.0-10.0 0.0-10.0
0-20 ppm 0.0-20.0 0.0-20.0
0-50 ppm 0.0-50.0 0.0-50.0
0-100 ppm 0-100 0-100
0-200 ppm 0-200 0-200
0-500 ppm 0-500 0-500
0-999 ppm 0-999 0-999
0-100%LEL 0-100 0-100
0-25%O2 0.0-25.0 0.0-25.0
15-25%O2 15.0-25.0 15.0-25.0
4-20 mA 4.0-20.0 4.0-20.0
0-100 °C 0-100 0-100
0-150 °C 0-150 0-150
0-10 V 0.0-10.0 0.0-10.0
