168 H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015
Appendix C: Power Supply Set Dimensions
Use the tables below for checking the size of the power supply set and of the batteries.
C.1 H-S81-HS Control Panel Absorption
C.2 Absorption of Hochiki Conventional Detectors
Part Number Description
Qty. Standby
current
Total
standby
current
Current with
alarmed
control panel
Total current
with alarmed
control panel
PU-0001 Power supply set 1 6A
1
1 Power supply set standby current and current with alarmed control panel is considered with the battery charger
at maximum current supply condition (low batteries).
6A 6A
1
6A
PU-0002 Power supply set 1 8A
1
8A 8A
1
8A
H-S81-HS Base Central unit rack + S81-T8004-1 1 0.230A 0.230A 0.300A 0.300A
H-S81-HS I/O I/O rack + rack controller 0.050A 0.050A
S81-F3002 8 monitored input module 0.014A 0.048A
S81-F4001 Module with 1 x 4-20mA input 0.035A 0.050A
S81-F4002 Module with 2 x 4-20mA input 0.060A 0.050A
S81-F4003 Module with 8 x 4-20mA input 0.013A 0.050A
S81-F5001 Module with 8 x 500mA monitored outputs 0.035A 0.038A
S81-F5002 Module with 16 x 250mA non monitored outputs 0.010A 0.013A
S81-F5003 Module with 8 monitored outputs for sounders 0.038A 0.041A
S81-F5004 Module with 4 x 2A monitored outputs 0.020A 0.023A
S81-F6001 Fire extinguishing module 0.010A 0.013A
S81-F6002 Logic module 0.009A 0.012A
S81-F7002 Control module for ESP bus 0.090A 0.094A
S81-F7006 Modbus RTU Master/Slave module 0.014A 0.017A
S81-F7007 Control module for Honeywell bus 0.070A 0.074A
S81-F7008 Control module for scales 0.014A 0.017A
S81-F7009 Control module for Apollo bus 0.090A 0.094A
S81-F7010 Control module for System Sensor bus 0.039A 0.042A
Total standby current (A1) Alarmed (B1)
Part Number Description Qty.
Standby
current
Total
standby
current
Current with
alarmed
control panel
Total current
with alarmed
control panel
SLR-E3N Smoke detector 0.00004A 0.04000A
DCD-AE3 60°C combined heat detector 0.00004A 0.04000A
DFJ-AE3 60°C fixed temperature heat detector 0.00004A 0.04000A
DFJ-CE3 90°C fixed temperature heat detector 0.00004A 0.04000A
DRD-E IR flame detector 0.00007A 0.04000A
NO contact Normally open contact 0.00400A 0.02600A
NC contact Normally closed contact 0.02600A 0.00400A
Total standby current (A2) Alarmed (B2)
