162 H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015
Parts List Termination Modules
A.6 Termination Modules
A.7 Blank Panels
A.8 Cables
Part Number Description Notes
S81-T8001-1 16-terminal termination module. DIN bar installation
S81-T8002-1 Passive current loop/RS232/converter module DIN bar installation
S81-T8003-1 8-terminal termination module. DIN bar installation
S81-T8004-1 Default I/O module DIN bar installation
S81-T8005-1 20-terminal termination module. DIN bar installation
S81-T8006-1 Module with 8 x 4A 30 VDC relays DIN bar installation
S81-T8007-1 Module with 16 x 4A 30 VDC relays for flat cable DIN bar installation
S81-T8007-2 Module with 16 x 4A 30 VDC relays for S81-CCT1 cable DIN bar installation
S81-T8008-1 Module with 4 x 2A 30 VDC relays for sounder control DIN bar installation
Part Number Description Notes
S81-U0000-1 Blank panel with holes for Ethernet cables Takes the place of one module
S81-F0000-1 Aluminum blank panel Takes the place of one module
Part Number Description Length
S81-CTT1 16x0.22 cable for non duplicated modules 5 meters
S81-CTT1R 16x0.22 cable for duplicated modules 5 meters
S81-CTT2 2x0.5 cable for non duplicated modules 5 meters
S81-CTT2R 2x0.5 cable for duplicated modules 5 meters
S81-CTT3 8x0.5 cable for non duplicated modules 5 meters
S81-CTT3R 8x0.5 cable for duplicated modules 5 meters
S81-CTT3R1 8x0.5 cable for duplicated modules 5 meters
S81-CTT4 4x0.5 cable for non duplicated modules 5 meters
S81-CTT4R 4x0.5 cable for duplicated modules 5 meters
S81-CTT6 6x0.5 cable for non duplicated modules 5 meters
S81-CTT7 4x0.5 cable for non duplicated modules 5 meters
S81-CTT7R 4x0.5 cable for duplicated modules 5 meters
S81-CFT10/2 10-way flat cable for Host connection 2 meters
S81-CFT14/2 14-way flat cable 2 meters
S81-CFT20/05 20-way flat cable 5 centimeters
S81-CFT20/2 20-way flat cable 2 meters
S81-CVSC4 8-way RJ cable 19cm
S81-CVSC5 8-way RJ cable 36cm
S81-CVSC12 8-way RJ cable 60cm
