170 H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015
Power Supply Set Dimensions Absorption of Apollo Addressable Devices
C.5 Absorption of Apollo Addressable Devices
Part Number Description Qty.
Standby
current
Total
standby
current
Current
with
alarmed
control
panel
Total current
with alarmed
control
panel
55000-600 XP95 Optical smoke detector 0.00034A
55000-500 XP95 Ionization smoke detector 0.00028A
55000-268 /273 XP95 Reflective Beam 0.0050A 0.009A
55000-885 XP95 Multi-sensor detector 0.00050A
55000-400 XP95 Heat detector (Standard) 0.00025A
55000-401 XP95 Heat detector (High Temperature) 0.00025A
55100-905 XP95 Manual Call Point 0.00010A
55000-640 XP95 I.S. Optical smoke detector 0.00034A
55000-540 XP95 I.S. Ionization smoke detector 0.00030A
55000-440 XP95 I.S. Heat detector (Standard) 0.00030A
55100-940 XP95 I.S. Manual Call Point 0.00023A
55000-847 Standard Input/Output Unit 0.00125A
55000-875 Standard Mains Input/Output Unit 0.00125A
55000-843 Standard Switch Monitor 0.00125A
55000-841 Standard Switch Monitor Plus 0.00125A
55000-845 Standard Zone Monitor 0.0040A 0.011A
55000-852 Standard Sounder Control Unit 0.00195A
55000-803 Din Rail Input/Output Unit 0.0012A
55000-797 Din Rail Main Input/Output Unit 0.0015A
55000-822 Din Rail Switch Monitor 0.00073A
55000-821 Din Rail Switch Monitor Plus 0.00073A
55000-760 Din Rail mini Switch Monitor 0.00020A
55000-812 Din Rail Zone Monitor 0.0040A 0.0110A
55000-182 Din Rail Sounder Control Unit 0.00150A
55000-773MAR Marine Din Rail Zone Monitor 0.0040A 0.0110A
55000-772MAR Marine Din Rail Switch Monitor Plus 0.00073A
55000-181MAR Marine Din Rail Sounder Control Unit
58000-600MAR Discovery Marine Optical smoke detector 0.00030A 0.0035A
58000-400MAR Discovery Marine Heat detector 0.00040A 0.0035A
58000-700MAR Discovery Marine Multi-sensor detector 0.00040A 0.0035A
58100-940MAR Discovery Marine Manual Call Point
58100-975MAR Discovery Marine W.P. Manual Call Point 0.00010A 0.0040A
58000-600 Discovery Optical smoke detector 0.00030A 0.0035A
58000-500 Discovery Ionization smoke detector 0.00030A 0.0035A
58000-700 Discovery Multi-sensor detector 0.00040A 0.0035A
58000-300 Discovery Carbon Monoxide detector 0.00030A 0.0035A
58000-305 Discovery Heat/Carbon Monoxide 0.00040A 0.0035A
58000-400 Discovery Heat detector 0.00040A 0.0035A
58100-908 Discovery Manual call Point Red 0.00010A 0.0040A
58100-950 Discovery W.P. Manual call Point Red 0.00010A 0.0040A
45681-393 Discovery Sounder/Beacon Base 0.00035A
58000-005 Discovery Open Area Sounder/Beacon 0.00035A
55000-295 Intelligent Dual IR Flame detector ATEX
55000-021 Intelligent Triple IR Flame detector ATEX 0.00220A 0.0042A
Total standby current (A5) Alarmed (B5)
