Honeywell H-S81-HS - A.3: Central Unit Rack

H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015 161
Central Unit Rack Parts List
A.3 Central Unit Rack
A.4 I/O Rack
A.5 I/O Modules
Part Number Description Notes
S81-CU001-1 Central unit with 19 inch 3 unit aluminum slot
S81-U1002-1 Central processing unit
S81-E2003-1 Two slot bus for central unit
S81-U1006-1 Operator interface unit
S81-T8004-1 Default I/O module
S81-T8001-1 16-terminal termination module.
S81-T8007-1 16-relay termination module.
S81-T8002-1 RS232/Current loop converter module
S81-U0000-1 Blank panel for central unit
S81-F0000-1 Blank panel Used only in systems with single CPU
S81-CFT20/05 Flat cable for termination module 5 centimeter long
S81-CFT10/2 Flat cable for serial connection 2 meter long
S81-CFT14/2 Flat cable for S81-T8004-1 module connection 2 meter long
EDS-205 24VDC MOXA Ethernet Switch 5 x 10/100BaseT ports
Part Number Description Notes
S81-EU001-1 Expansion rack with 19 inch 3 unit aluminum slot
S81-E2001-1 13 slot bus for flat cable termination I/O module redundancy not allowed
S81-E2001-2 13 slot bus for multi-conductor cable termination I/O module redundancy allowed
S81-E2002-1 Controller rack module
Part Number Description Notes
S81-F3002-1 8 monitored input module Redundancy not possible
S81-F3002-2 8 monitored input module Redundancy possible
S81-F4001-1 Module with 1 x 4-20mA analog input Redundancy not possible
S81-F4001-2 Module with 1 x 4-20mA analog input Redundancy possible
S81-F4002-1 Module with 2 x 4-20mA analog input Redundancy not possible
S81-F4002-2 Module with 2 x 4-20mA analog input Redundancy possible
S81-F4003-1 Module with 8 x 4-20mA analog input Redundancy not possible
S81-F4003-2 Module with 8 x 4-20mA analog input Redundancy possible
S81-F5001-1 Module with 8 x 500mA monitored outputs Redundancy not possible
S81-F5001-2 Module with 8 x 500mA monitored outputs Redundancy possible
S81-F5002-1 Module with 16 x 250mA non monitored outputs Redundancy not possible
S81-F5003-1 Module with 8 x 250mA monitored Redundancy not possible
S81-F5004-1 Module with 4 x 2A monitored outputs for solenoids Redundancy not possible
S81-F5004-2 Module with 4 x 2A monitored outputs for solenoids Redundancy possible
S81-F6001-1 Fire extinguishing module Redundancy possible
S81-F6002-1 Logic module Redundancy possible
S81-F7002-1 Loop control module for ESP addressable devices Redundancy not possible
S81-F7006-1 Modbus RTU Master/Slave module Redundancy not possible
S81-F7007-1 Control module for Honeywell bus Redundancy not possible
S81-F7008-1 Control module for scales Redundancy not possible
S81-F7009-1 Control module for Apollo bus Redundancy not possible
S81-F7010-1 Control module for System Sensor bus Redundancy not possible
