Appendix A: Parts List
The tables below list the modules, expansion modules and devices making up the H-S81-HS sys-
tem, sorted by product type.
A.1 Steelwork
A.2 Power Supply Sets
Part Number Description Notes
S81-CB001 Single rack control panel steelwork (wall installation) H700mm, W600mm, D400mm
S81-CB002 Double rack control panel steelwork (wall installation) H1100mm, W600mm, D400mm
S81-CB003 1 to 10 rack control panel steelwork (ground floor installation) H2100mm, W800mm, D800mm
Part Number Description Notes
S81-PU001-1 Power supply set with one PU-A0005-1 module 25V-4A
S81-PU001-2 Power supply set with two PU-A0005-1 modules 25V-4A
S81-PU001-4 Power supply set with four PU-A0005-1 modules 25V-16A
PU-A0005-1 125Watt Power supply unit module for S81-PU001
PU-A0004-1 Battery charger module for S81-PU001 Maximum current 4A
S81-PU002-2 Power supply set with two PU-A0008-1 modules
S81-PU002-4 Power supply set with four PU-A0008-1 modules
PU-A0007-1 Slot with cooling unit for S81-PU002
PU-A0008-1 500Watt Power supply unit module for S81-PU002
PU-A0009-1 Battery charger module for S81-PU002 Maximum current 6A
B84115-E-B110 115/250Vac 10A 50/60Hz line trap
LS502 Disconnect switch with fuses for batteries
FS20 10x38 20A fuse For battery disconnect switch
FS50 10x38 50° fuse For battery disconnect switch
F6.3 Ultra rapid 5x20 6.3A fuse For PU-A0005-1
F10 Ultra rapid 5x20 10A fuse For PU-A0008-1
SK12-26 12V 26A/h batteries
SK12-65 12V 65A/h batteries
SK12-120 12V 120A/h batteries
