Honeywell H-S81-HS User Manual

H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015 169
Absorption of Hochiki Addressable Devices Power Supply Set Dimensions
C.3 Absorption of Hochiki Addressable Devices
C.4 Absorption of Honeywell Addressable Devices
(A) both channels alarmed
Part Number Description Qty.
Standby
current
Total
standby
current
Current with
alarmed
control panel
Total current
with alarmed
control
panel
ALG-E, ALG-EN Photoelectric Smoke Sensor 0.00040A 0.00910A
ATG-E Heat Sensor 0.00036A 0.01900A
ACB-E, ACB-EW Multi Heat Sensor 0.00035A 0.01900A
AIE-E Ionization Smoke Sensor 0.00031A 0.01900A
ACA-E Smoke/Heat Multi Sensor 0.00045A 0.01900A
S81-Mod-An 4-20mA Analog Module 0.00022A 0.00500A
CHQ-CP, HCP-E, HCP-W Manual Call Point 0.00025A 0.00500A
CHQ-MZ,CHQ-SZM Single Zone Module 0.00026A 0.02200A
CHQ-Z, CHQ-DZM Dual Zone Module 0.00033A 0.03000A
CHQ-SIM Single Input Module 0.00015A 0.00015A
CHQ-S, CHQ-DIM Dual Input Module 0.00028A 0.00430A
CHQ-R, CHQ-DRC Dual Relay Controller 0.00030A 0.01600A
CHQ-B, CHQ-DSC Dual Sounder Controller 0.00034A 0.00800A
CHQ-PCM Plant Control Module 0.00030A 0.00200A
YBO-BS Base Sounder 0.00080A 0.01600A
CHQ-BS Base Sounder (Old type) 0.00080A 0.01600A
YBO-BSB Base Sounder Beacon 0.00025A 0.02100A
CHQ-WS2 Wall Sounder 0.00020A 0.00800A
CHQ-WSB Wall Sounder Beacon 0.00020A 0.00800A
CHQ-AB Addressable Beacon 0.00024A 0.00430A
CHQ-ARI Remote Indicator 0.00030A 0.00450A
Total standby current (A3) Alarmed (B3)
Part Number Description Qty.
Standby
current
Total
standby
current
Current with
alarmed
control panel
Total current
with alarmed
control
panel
S81-Mod-DI Module with 8 non monitored inputs 0.00025A 0.01000A
S81-Mod-AIT Module with 4 monitored inputs 0.00025A 0.01000A
S81-Mod-AI020 Module with 1 x 4-20 mA input 0.00025A 0.01600A
S81-Mod-AV010 Module with 1 x 0-10V input 0.00025A 0.01000A
S81-Mod-DO Module with 8 open collector outputs 0.00025A 0.01000A
S81-Mod-DISP 255 message display module 0.03000A 0.05000A
Total standby current (A4) Alarmed (B4)
