H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015 171
Absorption of System Sensor Addressable Devices Power Supply Set Dimensions
C.6 Absorption of System Sensor Addressable Devices
Part Number Description Qty.
Quiescent
current
Total
quiescent
current
Current with
alarmed
control panel
Total current
with alarmed
control
panel
CMA1-I Module with 1 output 0.00041A
M701E Module with 1 output
MMA1-I Module with 1 input 0.00040A
M710E Module with 1 input 0.00031A
M720E Module with 2 inputs 0.00034A
CMA11 Module with 1 input + 1 output 0.00050A
M721E Module with 2 inputs + 1 output 0.00034A
CMA22 Module with 2 inputs + 2 outputs
CMX-10RM Module with 5 inputs + 5 outputs
MCX-55M Module with 5 inputs + 5 outputs
MMX-10M Module with 10 inputs 0.0027A
CMX-10RM Module with 10 relay outputs 0.0030A
M710ECZ Module with 1 input for conventional detectors
M710ECZR Module with 1 input for conventional detectors, EExd
MMT 1 channel 4-20mA analog module
IIG4N 4 channel 4-20mA analog module 0.010A
M700KW Red alarm button for outdoor installation 0.00035A 0.0060A
M700KI Red alarm button 0.00035A 0.0060A
M700KACI-FG-B Blue alarm button 0.00035A 0.0060A
M700KACI-FG-B Yellow alarm button 0.00035A 0.0060A
ABS32/PW-I Addressable sounder base 0.0020A
ABSB32/PW/RD-I Addressable sounder base + beacon 0.0050A
AWB/RD-I Addressable beacon 0.0025A
AWS32/R/RD-I Electronic sounder with beacon 0.0050A
AWS32/R-I Electronic sounder 0.0030A
NFXI-SS-W Addressable sounder base 0.00015A
NFXI-BSF-WC Addressable sounder base + beacon 0.00022A
NFXI-WF-RR Addressable beacon 0.00012A
NFXI-WS-R Electronic sounder 0.00012A
NFXI-WSF-RR Electronic sounder + beacon 0.00012A
NFXI-OPT Optical smoke sensor 0.00025A
NFXI-TDIFF Rate of rise + fixed 58°C temp. heat detector 0.00020A
NFXI-TFIX58 58° heat sensor with isolator 0.00020A
NFXI-TFIX78 78° heat sensor with isolator 0.00020A
NFXI-SMT2 Optical/rate of rise heat detector 0.00025A
NFXI-SMT3 Optical smoke/ heat/flame IR detector 0.00020A
SDX-751CTEM Optical smoke/ heat/CO/flame IR detector 0.00020 0.0070A
7251 PINNACLE Laser smoke detector 0.00023A 0.00033A
SDX-751ME Optical smoke sensor 0.00030A 0.0070A
FDX551REM Rate of rise heat detector 0.00015A 0.0050A
FDX-551HTE 78° heat sensor 0.00015A 0.0050A
FDX-751-TEMI Optical/rate of rise heat detector
IDX751AE Intrinsically safe optical sensor
Total quiescent current (A6) Alarmed (B6)
