54 H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015
Parts of the H-S81-HS System I/O modules
Configuration
By using the configuration program ProS81, the following parameters can be set for each input
channel:
Threshold Setting
The following parameters can be set for each module through the configuration program or directly
on the control panel in the operator cycle, access level 3:
• Pre-alarm threshold.
• Alarm threshold.
• Current value below which a trouble condition is signaled.
• Calibration mixture concentration value for end of scale calibration.
Zero Point Calibration
Calibrate the zero point as reported below:
• Disable the channel of the module to be calibrated from the operator cycle.
• Enter the diagnosis cycle of the module to be calibrated.
• Make sure that no gas is present near the sensor to be calibrated.
• Press the “1” key to calibrate the zero point of the channel 1.
• Press “0” to cancel the operation for the channel 1.
• Press the “5” key to calibrate the zero point of the channel 2.
• Press the “4” key to cancel the operation for the channel 2.
• Exit the module diagnosis cycle and enable the channel.
NOTE: The two 3-digit displays on module front panel do not provide the operator with
fundamental information and do not comply with the standard EN-54-2.
Function Allowed values
Operating mode Latching/Non latching, UP/Down, NM
Mode of analog value transfer to Hosts Upon request/Automatic in case of change
Unit of measure of the channel Ppm, %LEL, %O2, mA, °C, RH, V, bar, db, rpm
Zero Point of the measuring range -999 - 999
End of scale of the measuring range -999 - 999
Pre-alarm threshold -999 - 999
Alarm threshold -999 - 999
Lower trouble threshold 1.0 - 3.8mA
Alarm delay 0 - 255 seconds
Type of indication Fire, Supervisory, Gas, Trouble, Hidden, Buzzer Only
Automatic alarm reset Yes/No
Enable/Disable status export via ModBus Yes/No
Enable/Disable channel status export to Hosts No, TCP1, TCP2, RS232
Enable/Disable commands from Hosts on the channel No, TCP1, TCP2, RS232
It defines the format of the analog value sent via ModBus,
and automatically via Host
mA, mA tenth, VI, VI tenth, converter points
NOTE: The zero point can be calibrated only with zero values ranging between 3 and 5mA.
