18 H-S81-HS Installation & Operation Manual — P/N LS10114-000HI-E:A 2/24/2015
General Description General Features
1.3.2 Electrical Characteristics
1.3.3 Reference Standards
The H-S81-HS system was developed complying with the requirements of the following European
standards:
1.3.4 Climatic Conditions
The table below summarizes the climatic conditions for H-S81-HS system operation and storage.
The climatic conditions refer to the whole system.
1.3.5 Mechanical Conditions
The table below summarizes the type of mechanical tests undergone by the H-S81-HS system.
• Supply voltage 110-240 V~ (-15% + 10%)
• Nominal frequency of the power supply 50-60Hz
• Power supply set output voltage 25VDC ±2%
Reference standard Description
EN-54-2:1997 / A1:2006 Fire detection and fire alarm systems
Part 2: Control and indicating equipment
EN-54-4: 1997 / A1:2002 / A2:2006 Fire detection and fire alarm systems
Part 4: Power supply equipment
EN-12094-1:2003 Fixed firefighting systems. Components for gas extinguishing systems.
Requirements and test methods for electrical automatic control and delay devices
EN-60950-1:2001 Information technology equipment – Safety - part 1:
General requirements
CEI 79-2:1998 + Ab2000 Intruder, burglar, hold up and anti-attack alarm systems. Particular requirements
for apparatus.
Parameter Allowed range Notes
Operating temperature -5 - 50°C
Storage temperature -40 - 85°C
Operating humidity 5 - 95% RH Non-condensing
Storage humidity 5 - 95% RH Non-condensing
NOTE: The operating temperature inside an electronic device significantly affects the duration of
its useful life. High operating temperatures and sharp temperature increases will significantly
reduce electronic device life. It is extremely important that the environmental operating conditions
are within the allowed ranges.
!
WARNING: REMOVE BATTERIES
SHOULD STORAGE TEMPERATURE BE LOWER THAN -30°C OR EXCEED +60°C, REMOVE
THE LITHIUM BATTERY ON CENTRAL UNITS (S81-U1002-1 MODULES).
Standard Test Test Levels
IEC 68-2-6 Vibration sinusoidal test (endurance) Frequency range: 10-150Hz
Acceleration amplitude: 0.5g
Number of axis: 3
Number of sweep cycles: 20 per axis
IEC 817 Impact test Impact energy: 0.5J
Number of impact per point: 3
