Honeywell UDC2800 User Manual

Step Operation Press Result
2 Enter Input
set up
group
Setup key Until you see Input N (N=1 or 2).
Function
key
Enter into the first function prompt Input N Type of
the Input set up group. N=1 or 2.
Press the Function key again to enter into the
configuration prompt of Input N Type.
Increment
key or
Decrement
key
To change the current selection to another
selection.
3 Scroll
through
Functions
Function
key
until the lower display rolls through the rest of the
functions and returns to Input N Type (N = 1 or 2)
Increment
key or
Decrement
key
until you change the input selection back to the
proper selection.
4 Return to
Normal
Operation
Lower
Display key
return to Normal operating mode.
The factory calibration will be restored. If the
problem is not corrected, contact your Honeywell
representative.
239
Chapter 6 - Input Calibration

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
